| Kondisi | Used |
|---|---|
| Lokasi | BANTEN |
Dijual Excavator :
- Merek Hitachi
- Model EX1200-6
- Ex Import / Built Up
- Masuk Indonesia tahun 2015
- Harga Rp. 5,5 Milyar.
Rp. 5,5 M
Technical Specifications
| Max Cutting Height | 12411.5 mm |
|---|---|
| Boom Length | 7501.1 mm |
| Boom/Stick Option (Hex) 1 | Boom- 7.5 m 24 ft. 9 in. / Arm 3.4 m 11 ft. 2 in. |
| Bucket Digging Force - Sae | 52209.5 kg |
| Arm Crowd Force - Sae | 43337.9 kg |
| Max.Dumping Height | 8052.8 mm |
| Maximum Vertical Wallcut Depth | 5181.6 mm |
| Maximum Reach At Ground Level | 13362.4 mm |
| Arm Crowd Force-Iso | 44663.6 kg |
| Max Digging Depth | 8052.8 mm |
| Max Digging Reach | 13752.6 mm |
| Arm Length | 3401.6 mm |
| Arm Digging Force - Iso | 58021.8 kg |
| Max Cutting Height | 13463 mm |
| Bucket Digging Force - Sae | 44867.5 kg |
| Max Digging Reach | 15352.8 mm |
| Max Digging Depth | 9381.7 mm |
| Arm Length | 3602.7 mm |
| Maximum Reach At Ground Level | 15010.1 mm |
| Boom Length | 9000.7 mm |
| Boom/Stick Option (Hex) 2 | Boom-9.0 m 29 ft. 6 in. / Arm 3.6 m 11 ft. 10 in. |
| Arm Crowd Force-Iso | 43847.8 kg |
| Max.Dumping Height | 9080 mm |
| Arm Crowd Force-Sae | 43032 kg |
| Bucket Digging Force - Iso | 49150.3 kg |
| Max Vertical Wall Digging Depth | 6452.6 mm |
| Max Cutting Height | 14112.2 mm |
| Bucket Digging Force - Sae | 44867.5 kg |
| Arm Crowd Force-Iso | 35894 kg |
| Arm Crowd Force-Sae | 35282.2 kg |
| Arm Length | 4700 mm |
| Boom Length | 9000.7 mm |
| Boom/Stick Option (Hex) 3 | Boom-9.0 m 29 ft. 6 in. /Arm 4.7 m 15 ft. 5 in. |
| Bucket Digging Force - Iso | 49150.3 kg |
| Max Digging Depth | 10482.1 mm |
| Max Digging Reach | 16431.8 mm |
| Max Vertical Wall Digging Depth | 8052.8 mm |
| Max.Dumping Height | 9610.3 mm |
| Maximum Reach At Ground Level | 16111.7 mm |
| Max Cutting Height | 14252.4 mm |
| Max Vertical Wall Dig Depth | 9631.7 mm |
| Max Digging Depth | 11472.7 mm |
| Max Digging Reach | 17330.9 mm |
| Arm Crowd Force-Iso | 31713.2 kg |
| Bucket Digging Force - Sae | 31611.2 kg |
| Max.Dumping Height | 10360.2 mm |
| Bucket Digging Force - Iso | 35078.2 kg |
| Boom/Stick Option (Hex) 4 | Boom- 9.0 m 29 ft. 6 in. / Arm 6.0 m 19 ft. 8 in. |
| Maximum Reach At Ground Level | 17032.2 mm |
| Boom Length | 9000.7 mm |
| Arm Length | 6001.5 mm |
| Arm Crowd Force-Sae | 31101.3 kg |
| Ground Clearance | 1021.1 mm |
| Track Gauge | 3901.4 mm |
| Track Length On Ground | 5090.2 mm |
| Width Over Standard Tracks | 4602.5 mm |
| Dig Depth - 2.44m 8 Ft Flat Bottom | 9262.9 mm |
| Dump Height - Mono Boom | 9080 mm |
| Transport Height - Maximum | 6861 mm |
| Dig Depth | 9380.2 mm |
| Digging Reach - Mono Boom | 15352.8 mm |
| Dig Height - Mono Boom | 13463 mm |
| Transport Length | 15970.3 mm |
| Overall Width | 5382.8 mm |
| Tailswing Radius | 4852.4 mm |
| Undercarriage Overall Length | 6501.4 mm |
| Ground Level Reach - Mono Boom | 15011.4 mm |
| Emissions Certification | U.S.EPA Tier2 |
| Starting System | 24 V electric motor |
| Piston Displacement | 23.2 L |
| Engine Model | Cummins QSK23-C |
| Engine Type | 4 cycle |
| Gross Power | 567 kw |
| Net Power | 552 kw |
| Aspiration | Water-cooled 6-cylinder in line |
| Bore | 170.2 mm |
| Stroke | 170.2 mm |
| Maximum Torque | 3468 Nm |
| Displacement | 23.2 L |
| Emission Rating | Tier 2 |
| Rated Speed | 1800 rpm |
| Engine Output - Net | 551.8 kw |
| Carrier Rollers - Each Side | 3 |
| Track Rollers - Each Side | 8 |
| Track Shoe Width | 701 mm |
| Number Of Cylinders | 6 |
| Hydraulic Oil Tank | 610.2 L |
| Fuel Tank | 1470.3 L |
| Hydraulic System | 1350.3 L |
| Engine Oil | 70 L |
| Engine Coolant | 139.3 L |
| Pump Drive | 15.1 L |
| Ground Bearing Pressure | 142 kPa |
| Dipper Tearout | 43847.8 kg |
| Operating Weight - Maximum | 111500 kg |
